Advantech HIT-W153 Intel® Pentium® N4200 39.6 cm (15.6") 1920 x 1080 pixels Touchscreen All-in-One PC 4 GB DDR3L-SDRAM 64 GB SSD Windows 10 IoT Enterprise Wi-Fi 5 (802.11ac) White
HIT-W153 is an innovative product in the HIT-series, featuring a 43mm thin body enclosure, USB 3.0, 5 megapixel camera, and dual isolated Ethernet, which lets hospitals separate and manage internal and external network traffic. The HIT-W153 also features a dedicated audio codec for our background noise-canceling handset to guarantee the best audio quality for calls to nurse stations. The available nurse call button and the LED indicator can be easily linked to existing nurse call systems in hospitals, and can be operated independently, even when the system is off. HIT-W153 is ideal for applications in hospitals, such as bedside information terminals, IP nurse call stations, and treatment centers. It can also be used as an HMI interface for medical equipment.
- Medical and ITE dual certification (EN 60601-1 & IEC 62368) to provide complete application coverage
- Rich optional peripherals – Handset / TV Tuner (SMA Jack)/2nd Smart Card Reader, Barcode Scanner/PoE, RFID+HID
- Supports nurse call button & LED indicator
- Dual isolated Ethernet – Internet (for patients) and intranet (for hospitals) network traffic management and data security
- Supports RFID/NFC/Web Camera/Smart Card Reader
- Supports M.2 2230 WiFi / BT modules and M.2 2242 SSDs
- All-in-one computer with Intel Apollo Lake N4200 CPU
- Innovative and ultra-slim design for healthcare and hospitality applications
| Bluetooth: | Yes |
|---|---|
| Built-in camera: | Yes |
| Built-in speaker(s): | Yes |
| Discrete graphics card: | No |
| Discrete graphics card model: | Not available |
| Display diagonal: | 39.6 cm (15.6") |
| Display resolution: | 1920 x 1080 pixels |
| Ethernet LAN: | Yes |
| HD type: | Full HD |
| Internal memory: | 4 GB |
| Maximum internal memory: | 8 GB |
| On-board graphics card model: | Intel® HD Graphics 505 |
| Operating system installed: | Windows 10 IoT Enterprise |
| Processor family: | Intel® Pentium® |
| Processor frequency: | 1.1 GHz |
| Processor manufacturer: | Intel |
| Processor model: | N4200 |
| Product colour: | White |
| Product type: | All-in-One PC |
| Storage media: | SSD |
| Top Wi-Fi standard: | Wi-Fi 5 (802.11ac) |
| Total storage capacity: | 64 GB |
| Touchscreen: | Yes |
| USB 2.0 ports quantity: | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: | 1 |
| Wi-Fi: | Yes |
