Advantech TPC-5172T Intel® Core™ i3 i3-6100 43.2 cm (17") 1280 x 1024 pixels Touchscreen 8 GB DDR4-SDRAM Black
Introduction
The TPC-5000 series is the first of Advantech’s TPC range of modularized industrial panel solutions. TPC-5000 series systems comprise a box module powered by a 6th Gen Intel®
Core™/Celeron® processor combined with an industrial-grade LED LCD module, providing compact and fanless control panel solutions that support high-performance computing.
Built to withstand diverse industrial environments, the TPC-5000 display modules feature an IP66-rated front panel for water and dust resistance, a scratch-resistant glass panel
that supports projected capacitive or 5-wire resistive touch control, and a robust enclosure with die-cast aluminum alloy front bezel. Meanwhile, the TPC-5000 box modules feature
MRAM and TPM 2.0 technology and 3 x LANs with surge protection and multiple fieldbus protocol support for increased data security and network connectivity. Designed for flexible
expansion and easy maintenance, TPC-5000 series systems can also be integrated with optional iDoor and Wi-Fi/NFC modules for enhanced functionality.
- Intel® Core™ i3-6100U processor with 8 GB of DDR4 SODIMM
- Industrial-grade LED LCD with a lifespan of 50,000 hours
- Modular design for flexible configuration and easy maintenance
- Display panel modules available in various sizes with either projectedcapacitive touch functionality for multi-touch control or 5-wire resistive touchfunctionality
- Intelligent home key and iKey provide intuitive user interfaces for systemcontrol
- Built-in Trusted Platform Module (TPM) 2.0
- 1 x full-size mini-PCIe with iDoor technology and 1 x half-size PCIe
- IP66-compliant front panel protection & supports SSD expansion
- 3 x LAN with multiple fieldbus protocol support and LAN surge protection
- IEC 61010-2 compliant (only panels of certain sizes)
- Logo can be customized without changing the touchscreen
| Display diagonal: | 43.2 cm (17") |
|---|---|
| Display resolution: | 1280 x 1024 pixels |
| Ethernet LAN: | Yes |
| HD type: | HD+ |
| Internal memory: | 8 GB |
| Maximum internal memory: | 16 GB |
| Processor family: | Intel® Core™ i3 |
| Processor frequency: | 2.3 GHz |
| Processor manufacturer: | Intel |
| Processor model: | i3-6100 |
| Product colour: | Black |
| Touchscreen: | Yes |
| USB 2.0 ports quantity: | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: | 2 |
